| Content |
| Color |
Iron Grey |
| Max Number of External Monitors |
1 |
| New Weight |
156 g |
| Refresh Rate |
3840 x 2160 / 60 Hz |
| AC Plug |
USB-C |
| Hardware Requirements |
Full featured USB-C port including PD, DP, USB |
| Warranty Type |
Customer Replaceable Unit (CRU) |
| Output Power |
45W |
| Brand |
Lenovo |
| OS Requirements |
Windows 11, Windows 10 |
| Packed Weight |
650 g |
| Agency Approvals |
CB, BSMI, SII, CU, Ukraine, Kvalitet, LOA, NOM, cULus, FCC, ICES, CE, RCM, VCCI, KCC, EAC |
| Audio Ports |
1x 3.5 mm combo jack |
| Charging Port |
USB-C |
| USB Ports |
1*USB-C 3.1 Gen1, 1*USB-A 3.1 Gen1, 1*USB2.0 |
| Video Ports |
1x HDMI2.0 (supports up to 4K@60Hz, HDR&HDCP2.2); 1x VGA port (supports up to 1080p@60Hz); Only one external display can be connected to the dock at one time. |
| Ethernet |
Gigabit RJ45 |
| Package Type |
Brown Box |
| Packed Dimensions (L x D x H) |
215mm x 100mm x 65mm |
| Height |
17 mm (0.66 in) |
| New Cable Length |
180 mm |
| Depth |
53 mm (2.08 in) |
| Warranty Period |
1 Year |
| Maximum Operating Temperature |
-5°C |
| Minimum Operating Temperature |
-5°C |
| Maximum Relative Humidity (%) |
95% |
| Minimum Relative Humidity (%) |
20% |
| Driver Needed |
USB to Ethernet Driver |
| Input Power |
65W |
| Physical Security Feature |
NA |
| Power Button |
No |
| Power Delivery |
Yes |
| Weight |
156g |
| Warranty |
Customer Replaceable Unit (CRU) |
| | | | Physical Specifications
- Video Ports:
- Two DisplayPort (DP)
- One HDMI
- USB Ports:
- Three USB 3.1
- Two USB 2.0
- One USB-C
- Audio Ports: Combo Audio Jack
- Ethernet: Gigabit Ethernet
- Physical Security Feature: Security lock slot
- Maximum Number of External Monitors: 3
- Maximum Resolution and Refresh Rate
- Two at 3840x2160 @60Hz;
- One at 3840x2160 @30Hz
- Charging Port: DC-IN
- Input Power: 90W
- Power Delivery: Yes
- Output Power: 65W with 90W power adapter connected;100W with 135W power adapter connected
- Power Button: Yes
- Power Plug: Slim-tip
- Dimensions
- Length: 171 mm (6.7 inches)
- Depth: 80 mm (3.1 inches)
- Height: 31 mm (1.2 inches)
- Weight: 340 g (0.74 lb)
- Packaged Dimensions:
- Length: 210 mm (8.3 inches)
- Depth: 158 mm (6.2 inches)
- Heigh: 75 mm (3.0 inches)
- Packaged Weight: 955 g (2.1 lb)
- Agency Approvals: FCC/ICES; CE; KCC; RCM; BSMI; VCCI; CB; cULus; EAC; TUV- Mark; Serbia Kvalitet; LoA; Israel SII; Ukraine DoC; NOM
Operating Environment
- Minimum Operating Temperature: 0° C
- Maximum Operating Temperature: 35° C
- Minimum Relative Humidity (%): 20%
- Maximum Relative Humidity (%): 95% ( no Condensation)
| |
